A-SWD5 Surface Wedge


Standard without Blower & Heater Type
A-SWD5C (Clear)
A-SWD5T (Tinted)
Silver
A-SWD5CSV (Clear)
Silver
A-SWD5TSV(Tinted)
Housing & Camera Chart

Optional Items
A-SWD5WB2(W)

Universal Wall Mount Bracket^"WHITE"@Version

(for A-SWD5Z,A-SWD5V and A-SWD5VX)

A-SWD5WB2iBj

Universal Wall Mount Bracket^hBLACKh@Version

(for A-SWD5Z,A-SWD5V and A-SWD5VX)


A-SWD5CA2(W)

Universal Ceiling Mount Bracket

(for A-SWD5Z,A-SWD5V and A-SWD5VX)


A-SWD5BH2 24VAC Blower & 25Watts Heater
Controlled by thermostat automatically.

A-PS2412SWD5 24VAC-12VAC Power Converter
Features:
–A-PS2412 is the power converter from 24VAC to 12VDC Max.2.5A.
–Long Life owing to use of Made in Japan Condensor 105Ž 5000 hours spec.
–It has diagonostic LED both input 24VAC and output 12VDC.
–It is useful to supply 12VDC Camera Power when it is out of range of PoE..(over 100m=333ft)
–RoHS, UL(File #E313815), CE
(As regards UL, it is tested and approved as one of the housing components.)
